OPM-50 Intelligent Optical Power Meter

OPM-50 Intelligent Optical Power Meter


  Automatic wavelength identification

  Remote reference value setting

  FTTx applicable

  Internal clock & fiber S/N editable

  Memory of 1000 test records

  Data Transfer to PC via USB

  USB power charging

  No warm-up, quick start

  Backlight

  70 hours continuous operation

  Pocketsize, lightweight and easy-to-use

  CE FCC certificates

OPM-50 paired with SLS-50 Intelligent Stabilized Laser Source can be used to identify fiber, measure attenuation and loss, verify continuity and evaluate fiber link transmission quality.



Automatic Wavelength Identification

Compatible with the digital encryption protocols of SLS-50, OPM-50 can automatically identify the wavelength of the optical signals transmitted from SLS-50 and switch to the corresponding test mode, which greatly reduces the workload at both ends and avoids potential error.

Remote Reference Value Setting

OPM-50 can receive the power parameters of digital-encrypted signal transmitted from SLS-50 as reference for precise link loss measurement even the two units are far apart.



Internal Clock & Fiber S/N Editable

Internal clock enables OPM-50 to save test data with time and editable fiber SN information.

Compatible with FTTx Test

OPM-50 can be applied to measure Triple-play signals (1310nm, 1490nm and 1550nm) on Passive Optical Network (PON).



Specifications

Model	OPM-50
	A	B
Calibrated Wavelength(1)	850,1300,1310,1490,1550,1625nm
Power Range (dBm)(2)	-70 ~ +10(1)	-50 ~ +27
Fiber Type	Singlemode/Multimode fibers
Detector Type	InGaAs
Accuracy	±5% ±0.01nW (±0.5dB@850nm)	±5% ±1nW (±0.5dB@850nm)
Resolution (dB)	0.01
MOD Identification	270, 1K, 2K Hz
Auto Wavelength Identification	Yes (With SLS-50)
Display Unit	W/mW/µW/nW/pW/dBm/dB(REF)
Data Storage	1000 records
Connectivity	USB
Connector(3)	FC (Interchangeable SC/ST)
Power Supply	Lithium Battery/ AC Adapter
Battery Life	Continuous operation: 70 hours, Standby: 140 hours
Power Saving	Auto-off after 5 minutes idle
Operating Temperature	0ºC ~ 50ºC (32 ~ 122 F)
Storage Temperature	-20ºC ~ 70ºC (-4 ~ 158 F )
Relative Humidity	0 ~ 95% (Non-condensing)
Weight	315g (0.69 lbs)
Dimensions (H × W × T)	177×80×44mm (6.97×3.15×1.73 inch)

Note: (1) Other wavelengths are open for customization;

           (2) For Model A at 850nm, the lower limit of measurement range is -60dBm (Model A) / -40dBm (Model B);

           (3) OPM models with Ф1000μm detector are available with: FC/SC/ST/DIN/E2000/LC/Universal

1.25mm/Universal 2.5mm connectors.

* Specifications subject to change without notice



Ordering Information

Standard Package Includes:

Instrument, Lithium battery, AC adapter, USB cable, OPM data analysis software CD, Soft carrying case, Warranty card, CE certificate, Certificate of calibration, User manual.
